- ASUS
Цена
€130 92 / 256 06 лв
с ДДС
* ВЪНШЕН ДОСТАВЧИК - (1 до 3 дни)
* - Стоката е в склад на официалния вносител на марката за България. Времето за доставка е обикновено от 1 до 3 работни дни. Възможно е към момента на завършване на поръчката, продукта да е вече изчерпан. В случай на изчерпана наличност ще се свържем с Вас
Информираме Ви, че въпреки нашите усилия не можем да гарантираме, че публикуваната информация и снимки не съдържат неточности или грешки, които не могат да бъдат правно основание за претенции.
Vendor_url
https://www.asus.com/motherboards-components/motherboards/csm/prime-b650-plus-csm/
Graphics
1 x DisplayPort
1 x HDMI® port
CPU's supported
AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
Chipset
AMD B650 Chipset
Expansion slots
AMD Ryzen™ 9000 & 7000 Series Desktop Processors
1 x PCIe 4.0 x16 slot (supports x16 mode)
AMD Ryzen™ 8000 Series Desktop Processors
1 x PCIe 4.0 x16 slot (supports x8/x4 mode)
AMD B650 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)
2 x PCIe 4.0 x1 slots
Storage
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
AMD Ryzen™ 9000 & 7000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/ 2260/ 2280/ 22110 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2242/ 2260/ 2280/ 22110 (supports PCIe 4.0 x4 mode)
AMD Ryzen™ 8000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/ 2260/ 2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/ 2260/ 2280/ 22110 (supports PCIe 4.0 x4/x2 mode)
AMD B650 Chipset
4 x SATA 6Gb/s ports
Memory type
4 x DIMM, Max. 192GB, DDR5 7600+(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5800(OC) / 5600(OC) / 5400(OC) / 5200/ 5000/ 4800 ECC and Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports AMD Extended Profiles for Overclocking (EXPO™)
OptiMem II
Rear panel I/O
4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C®)
2 x USB 3.2 Gen 1 ports (2 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x DisplayPort
1 x HDMI® port
1 x Vertical M.2 slot (Key E)
1 x Realtek 2.5Gb Ethernet port
5 x Audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack™ button
USB
Rear USB (Total 8 ports)
4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C®)
2 x USB 3.2 Gen 1 ports (2 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 7 ports)
1 x USB 3.2 Gen 1 connector (supports USB Type-C®)
1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Connectors
Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
3 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
2 x M.2 slots (Key M)4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 connector (supports USB Type-C® )
1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x SPI TPM header (14-1pin)
1 x 20-3 pin System Panel header with Chassis intrude function
1 x Thunderbolt™ (USB4®) header
Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
Lan
1 x Realtek 2.5Gb Ethernet
Wireless
Vertical M.2 slot only (Key E, PCIe)
BIOS
256 Mb Flash ROM, UEFI AMI BIOS
Form factor
ATX Form Factor, 30.5 cm x 24.4 cm
OS
Windows® 11, Windows® 10 64-bit
Warranty
36 Months
Данни, подадени от официалния вносител за България.
| Атрибут | Стойност |
|---|---|
| Vendor_url | https://www.asus.com/motherboards-components/motherboards/csm/prime-b650-plus-csm/ |
| Chipset | AMD B650 Chipset |
| OS | Windows® 11, Windows® 10 64-bit |
| Warranty | 36 Months |
| CPU's supported | AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors |
| Memory type | Dual channel memory architecture |
| Memory type | Supports AMD Extended Profiles for Overclocking (EXPO™) |
| Memory type | OptiMem II |
| Memory type | 4 x DIMM, Max. 192GB, DDR5 7600+(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC and Non-ECC, Un-buffered Memory |
| Form Factor | ATX Form Factor, 30.5 cm x 24.4 cm |
| Audio | - Dedicated audio PCB layers |
| Audio | - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking |
| Audio | Audio Features |
| Audio | - Audio Shielding |
| Audio | - Supports up to 24-Bit/192 kHz playback |
| Audio | - Premium audio capacitors |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC |
| Rear panel I/O | 1 x DisplayPort |
| Rear panel I/O | 2 x USB 2.0 ports (2 x Type-A) |
| Rear panel I/O | 1 x BIOS FlashBack™ button |
| Rear panel I/O | 1 x Realtek 2.5Gb Ethernet port |
| Rear panel I/O | 5 x Audio jacks |
| Rear panel I/O | 1 x Optical S/PDIF out port |
| Rear panel I/O | 4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C®) |
| Rear panel I/O | 2 x USB 3.2 Gen 1 ports (2 x Type-A) |
| Rear panel I/O | 1 x HDMI® port |
| Rear panel I/O | 1 x Vertical M.2 slot (Key E) |
| LAN | 1 x Realtek 2.5Gb Ethernet |
| Expansion Slots | 1 x PCIe 4.0 x16 slot (supports x16 mode) |
| Expansion Slots | AMD Ryzen™ 9000 & 7000 Series Desktop Processors |
| Expansion Slots | AMD Ryzen™ 8000 Series Desktop Processors |
| Expansion Slots | 1 x PCIe 4.0 x16 slot (supports x8/x4 mode) |
| Expansion Slots | 2 x PCIe 4.0 x1 slots |
| Expansion Slots | AMD B650 Chipset |
| Expansion Slots | 1 x PCIe 4.0 x16 slot (supports x4 mode) |
| Wireless | Vertical M.2 slot only (Key E, PCIe) |
| Graphics | 1 x DisplayPort |
| Graphics | 1 x HDMI® port |
| Features | ASUS Exclusive Software |
| Features | Armoury Crate |
| Features | AI Suite 3 |
| Features | ASUS CPU-Z |
| Features | WinRAR |
| Features | UEFI BIOS |
| Features | ASUS EZ DIY |
| Features | - ASUS CrashFree BIOS 3 |
| Features | - ASUS EZ Flash 3 |
| Features | - ASUS UEFI BIOS EZ Mode |
| Features | ASUS 5X PROTECTION III |
| Features | ASUS Q-Design |
| Features | ASUS Thermal Solution |
| Features | IT Management software supported |
| Features | - ASUS Control Center Express(ACCE) |
| Features | - DIGI+ VRM |
| Features | - LANGuard |
| Features | - Overvoltage Protection |
| Features | - Stainless-Steel Back I/O |
| Features | - Q-DIMM |
| Features | - Q-LED Core |
| Features | - Q-Slot |
| Features | Aura Sync |
| Features | - Addressable Gen 2 headers |
| Features | - Aura RGB header |
| Features | - Aura Creator |
| Features | - Aura Sync |
| Features | - Power Saving |
| Features | - TurboV EVO |
| Features | - VRM heatsink design |
| Features | - BIOS FlashBack™ button |
| Features | - BIOS FlashBack™ LED |
| Features | - SafeSlot Core+ |
| Features | - Fan Xpert 2+ |
| Features | - Flexible M.2 heatsink |
| Features | - ProCool |
| Features | Software Features: |
| Features | - DIGI+ VRM- PC Cleaner |
| Features | Norton Anti-virus software (Free Trial version) |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| I/O | 1 x DisplayPort |
| I/O | 5 x audio jacks |
| I/O | 2 x USB 2.0 ports (2 x Type-A) |
| I/O | 1 x BIOS FlashBack™ button |
| I/O | 1 x Realtek 2.5Gb Ethernet port |
| I/O | 1 x Optical S/PDIF out port |
| I/O | 4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C®) |
| I/O | 2 x USB 3.2 Gen 1 ports (2 x Type-A) |
| I/O | 1 x HDMI® port |
| I/O | 1 x Vertical M.2 slot (Key E) |
| Storage | 4 x SATA 6Gb/s ports |
| Storage | Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports |
| Storage | AMD Ryzen™ 9000 & 7000 Series Desktop Processors |
| Storage | AMD Ryzen™ 8000 Series Desktop Processors |
| Storage | M.2_1 slot (Key M), type 2242/ 2260/ 2280 (supports PCIe 4.0 x4 mode) |
| Storage | M.2_1 slot (Key M), type 2242/ 2260/ 2280/ 22110 (supports PCIe 5.0 x4 mode) |
| Storage | M.2_2 slot (Key M), type 2242/ 2260/ 2280/ 22110 (supports PCIe 4.0 x4 mode) |
| Storage | M.2_2 slot (Key M), type 2242/ 2260/ 2280/ 22110 (supports PCIe 4.0 x4/x2 mode) |
| Storage | AMD B650 Chipset |
| Connectors | 1 x COM port header |
| Connectors | Fan and Cooling related |
| Connectors | 1 x 4-pin CPU Fan header |
| Connectors | Power related |
| Connectors | 1 x 24-pin Main Power connector |
| Connectors | 1 x 8-pin +12V Power connector |
| Connectors | Storage related |
| Connectors | USB |
| Connectors | Miscellaneous |
| Connectors | 1 x Clear CMOS header |
| Connectors | 1 x Front Panel Audio header (AAFP) |
| Connectors | 1 x SPI TPM header (14-1pin) |
| Connectors | 2 x USB 2.0 headers support 4 additional USB 2.0 ports |
| Connectors | 3 x Addressable Gen 2 headers |
| Connectors | 1 x Aura RGB header |
| Connectors | 1 x 4-pin CPU OPT Fan header |
| Connectors | 1 x 4-pin AIO Pump header |
| Connectors | 3 x 4-pin Chassis Fan headers |
| Connectors | 1 x USB 3.2 Gen 1 connector (supports USB Type-C® ) |
| Connectors | 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports |
| Connectors | 1 x 20-3 pin System Panel header with Chassis intrude function |
| Connectors | 1 x Thunderbolt™ (USB4®) header |
| Connectors | 2 x M.2 slots (Key M)4 x SATA 6Gb/s ports |
| USB | 2 x USB 2.0 ports (2 x Type-A) |
| USB | Front USB (Total 7 ports) |
| USB | 2 x USB 2.0 headers support 4 additional USB 2.0 ports |
| USB | Rear USB (Total 8 ports) |
| USB | 4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C®) |
| USB | 2 x USB 3.2 Gen 1 ports (2 x Type-A) |
| USB | 1 x USB 3.2 Gen 1 connector (supports USB Type-C®) |
| USB | 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports |
| Тегло | 0.00кг |
Данни, автоматично извлечени от интернет. Точността не е гарантирана. За подробна информация, моля, свържете се с нас или посетете страницата на производителя.
| Атрибут | Стойност |
|---|---|
| Сокет | AM5 |
| Форм фактор | ATX |
| Чипсет | AMD B650 |
| Тип памет | DDR5 |
| Слотове за памет (count) | 4 |
| Максимална памет (GB) | 128 |
| M.2 слотове (count) | 2 |
| SATA портове (count) | 4 |
| PCIe x16 слотове (count) | 2 |
| Вграден Wi-Fi | Не |
| Скорост на LAN | 2.5 Gbps |
| USB-C портове (count) | 1 |
| RGB подсветка | Не |
| Тегло | 0.00кг |
ASUS PRIME B650-PLUS-CSM – Надеждна AM5 дънна платка за високопроизводителни компютри
Базирана на платформата AMD AM5, ASUS PRIME B650-PLUS-CSM осигурява солидна основа за вашето следващо поколение PC. С поддръжка на DDR5 памет и PCIe 5.0 свързаност, тази ATX дънна платка гарантира бърз трансфер на данни и готовност за бъдещето. Независимо дали изграждате гейминг машина или работна станция, серията PRIME предлага стабилна работа и широки опции за охлаждане.
Ключови Предимства
- AMD AM5 Сокет — Съвместимост с процесори Ryzen 7000, отключваща най-новите технологии.
- Поддръжка на DDR5 Памет — До 128GB DDR5 с честоти над 6000MHz за безпроблемна многозадачност.
- PCIe 5.0 x16 Слотове — Два пълноразмерни PCIe 5.0 слота за графични карти и NVMe SSD, осигуряващи максимална честотна лента.
- Двойни M.2 Слотове — Един PCIe 5.0 и един PCIe 4.0 M.2 слот за ултрабърза конфигурация на паметта.
- 2.5Gb Ethernet — Високоскоростна кабелна мрежа с Realtek 2.5Gb LAN за безпроблемна игра онлайн.
- Цялостно Охлаждане — Множество вентилаторни заглавни части, радиатори за VRM и поддръжка на AIO помпа за оптимално управление на температурата.
Технически Спецификации
| Спецификация | Стойност |
|---|---|
| Сокет | AM5 |
| Форм фактор | ATX |
| Чипсет | AMD B650 |
| Тип памет | DDR5 |
| Слотове за памет | 4 |
| Максимална памет | 128 GB |
| M.2 слотове | 2 (1x PCIe 5.0, 1x PCIe 4.0) |
| SATA портове | 4 |
| PCIe x16 слотове | 2 (и двата PCIe 5.0) |
| Скорост на LAN | 2.5 Gb Ethernet |
| USB-C портове | 1 (отзад) |
| RGB подсветка | Не (наличен Aura Sync хедър) |
Какво има в кутията
- ASUS PRIME B650-PLUS-CSM Дънна платка
- Ръководство за потребителя
- I/O Скоба
- 2x SATA 6Gb/s Кабела
- M.2 Гумен пакет
- Пакет с винтове за M.2 SSD
- ASUS Support DVD
